Tesla wall connector installed front view

Tesla Wall Connector Gen 3

Name: Tesla Wall Connector Gen 3 - Buy Now - Full Specifications - Reviews - Opinions - Make Informed Choice - EV Chargers Guide
Price: 420.00 USD
Availability: InStock
Rating: 4.67 (3 reviews)

★★★★★

(3 customer reviews)

$420.00

Check Best Deals Worldwide

Key Features:

Among Fastest Level 2 EVSE – 48 amp smart Home EV charging station – with 24-foot cable with integrated cable management

Max charging power: 11.5kW @48A single-phase
Charging speed: Up to 44 MPH
Charging connector: NACS
LED status lights: Yes

*Note: Prices and warranty details may change over time and the same will be updated here at the earliest. Check Best Deals Worldwide.

Category: Shop Home EV Chargers

Additional information
Reviews (3)

Specification: Tesla Wall Connector Gen 3

Basic Info

Charger Level	Level 2
EVs compatibility	All EVs, All non-Tesla with charging adapter
is Smart Charger?	Yes

Deployment

Convenience	Fixed solution at location of installation (Home-office etc)
Usage	Indoor, Outdoor

Power

Power supply connection	Hardwired
Power input	240V 15A to 60A Single phase or 400V 3-phase AC
Power load distribution	Single-phase & Three-phase
Frequency	50/60 Hz
Max power output	11.5kW @48A single-phase
Adjustable power output	Yes

Performance

Max charging speed (Range added per hour of charging in miles)	44 MPH

Hardware

No. of charging cables (No. of EVs can charge at a time)	1
Holster/Dock	Simple (Integrated in charging unit)
Charging cable management system	Integrated in unit
Cable length	24-ft (7.3m)
Charging connector	NACS
Power adapters in pack	Not needed
Latch/Lock button on charging handle	Yes
Auto sensor button on handle to open charge port	Yes (Works for Tesla only)

Smart Charging Functions

LED status lights	Yes
App integration	Yes
Wi-Fi/Internet connectivity	Yes (2.4GHz)
Schedule charging	Yes
Charging Stats reporting	Yes
Power load sharing (Between multiple chargers on same circuit)	Yes
Access control	Yes
RFID feature	No
Voice Assistant	No
Automatically resume charging after power outage	Yes
Auto troubleshooting	No
Integrated utility companies plans detail in App	Yes
Auto schedule Off-peak charging hours communication with utility providers	No
Integrated Distributed Energy Resource Management System (DERMS)	No
Software/Firmware updates	Yes
OCPP compliant software	No

Body

Dimension	345 mm (H) * 155 mm (W) * 110 mm (D)
Weight	10 lbs. (4.5 kg)

Ambient requirements

Storage temperature range	-40°F to +185°F (-40°C to +85°C)
Operating temperature range	-22°F to +122°F (-30°C to +50°C)
Ventilation	Not Required

Certifications

Weather protection (Enclosure Rating)	Nema 3R
Energy Star certified	Yes
Safety Certifications	UL

Installation

Mounting	Wall, Pedestal
Installation requirements	Requires certified electrician
Installation cost	Appx. $750 to $1500+

Miscellaneous

Warranty	48 months* (4 year) for residential use and 12 months (1 year) for commercial use
Eligible for Tax Credit/Rebates	Yes
What's in package	1x Charging Unit, 1x Mounting set, 1x Mounting Template, Installation guide, Quick Start guide

Buying Price (By Variant)

Buying Price (Single Variant)	$420

3 reviews for Tesla Wall Connector Gen 3

4.7 out of 5

★★★★★

Write a review

Show all Most Helpful Highest Rating Lowest Rating

★★★★★
Brian Green – June 20, 2024
I have a Tesla model Y. There’s really no other better option than Tesla’s wall connector for me. I bought this 2 years ago. And its working perfect.. I rarely used public charger since I installed this at my home.
I am going to have one more EV so let’s see if I can get its universal wall connector.
+ PROS: I really Tesla EV specific functions like opening of charge port with a button on charging handle. Plus adding to Tesla app it really makes it smart to use. For those using Tesla's energy devices ecosystem this is perfect one to fit in. Very much cost effective compared to smart functions it's built with. 4 Years of whooping warranty shows it's soundness.
- CONS: Nothing yet
Helpful(0) Unhelpful(0)You have already voted this
★★★★★
Zach Picklesimer – June 20, 2024
For Tesla users it’s just perfect unit. But for non-Tesla EVs there are much better options available. But still making this a worth charger even if you have other EV, you can use with an adapter.
Helpful(0) Unhelpful(0)You have already voted this
★★★★★
Ken Wilson – June 25, 2024
I use wall connector for my Tesla MS and MY, it is working all good. Using Tesla app for charging related settings. All important things for charging are working well. No complaints.
Plus my utility provider offered a great deal on rebate using this charger. So very happy with using Tesla car and charger both.
Helpful(0) Unhelpful(0)You have already voted this
