Basic Info |
|---|
| Charger Level | Level 2 |
|---|
| EVs compatibility | All EVs |
|---|
| is Smart Charger? | Yes |
|---|
|
|
Deployment |
|---|
| Convenience | Fixed solution at location of installation (Home-office etc) |
|---|
| Usage | Indoor, Outdoor |
|---|
|
|
Power |
|---|
| Power supply connection | Plug-in, Hardwired |
|---|
| Power input | 208V/240V 20A-60A AC |
|---|
| Power load distribution | Single-phase |
|---|
| Frequency | 60Hz |
|---|
| Max power output | 9.6kW @40A – 11.5kW @48A |
|---|
| Adjustable power output | Yes |
|---|
|
|
Performance |
|---|
| Max charging speed (Range added per hour of charging in miles) | 30 MPH to 44 MPH |
|---|
|
|
Hardware |
|---|
| No. of charging cables (No. of EVs can charge at a time) | 1 |
|---|
| Holster/Dock | Simple (Separate from charging unit) |
|---|
| Charging cable management system | Integrated in unit |
|---|
| Cable length | 25-ft (7.6m) |
|---|
| Charging connector | J1772 Type 1 |
|---|
| Power adapters in pack | Plug-in: Nema 14-50 / Hardwire: Not needed |
|---|
| Latch/Lock button on charging handle | Yes |
|---|
| Auto sensor button on handle to open charge port | No |
|---|
|
|
Smart Charging Functions |
|---|
| LED status lights | Yes |
|---|
| App integration | Yes |
|---|
| Wi-Fi/Internet connectivity | Yes (2.4/5GHz) |
|---|
| Schedule charging | Yes |
|---|
| Charging Stats reporting | Yes |
|---|
| Power load sharing (Between multiple chargers on same circuit) | Yes |
|---|
| Access control | Given just 'Lock/Unlock Mode' in App to lock EV charger, so noone else can use EV charger when in Lock Mode. But it's not proper access control feature. |
|---|
| RFID feature | Yes |
|---|
| Voice Assistant | Yes – Alexa, Google |
|---|
| Automatically resume charging after power outage | Yes |
|---|
| Auto troubleshooting | No |
|---|
| Integrated utility companies plans detail in App | No |
|---|
| Auto schedule Off-peak charging hours communication with utility providers | No |
|---|
| Integrated Distributed Energy Resource Management System (DERMS) | Yes |
|---|
| Software/Firmware updates | Yes |
|---|
| OCPP compliant software | Yes |
|---|
|
|
Body |
|---|
| Dimension | 198 mm (H) * 200 mm (W) * 99 mm (D) |
|---|
| Weight | 4.4 lbs. (2 kg) |
|---|
|
|
Ambient requirements |
|---|
| Storage temperature range | -22°F to +104°F (-30°C to +40°C) |
|---|
| Operating temperature range | -40°F to +158°F (-40°C to +70°C) |
|---|
| Ventilation | Sufficient Ventilated Location |
|---|
|
|
Certifications |
|---|
| Weather protection (Enclosure Rating) | Nema 4 |
|---|
| Energy Star certified | Yes |
|---|
| Safety Certifications | FCC, UL |
|---|
|
|
Installation |
|---|
| Mounting | Wall, Pedestal, Pole |
|---|
| Installation requirements | Plug-in: Ready to use if 240V wall outlet is ready, Else for Plug-in/Hardwired: Requires certified electrician |
|---|
| Installation cost | Plug-in: Almost No Cost if 240V Powerline and wall outlet is ready, Else for Plug-in/Hardwired: Appx. $500 to $1500+ |
|---|
|
|
Miscellaneous |
|---|
| Warranty | 36 months* (3 years*) |
|---|
| Eligible for Tax Credit/Rebates | Yes |
|---|
| What's in package | 1x Charging Unit, 1x Mounting set, Holster, Amperage Lables, Installation guide |
|---|
|
|
Buying Price (By Variant) |
|---|
| 40A | Hardwired | J1772 | $649* |
|---|
| 48A | Hardwired | J1772 | $699* |
|---|
| 40A | Plug-in | Nema 14-50 | J1772 | $649* |
|---|
|
