Basic Info |
---|
Charger Level | Level 1, Level 2 |
---|
EVs compatibility | All EVs |
---|
is Smart Charger? | No |
---|
|
Deployment |
---|
Convenience | Portable/Fixed solution at location of installation (Home-office etc) |
---|
Usage | Indoor, Outdoor |
---|
|
Power |
---|
Power supply connection | Plug-in |
---|
Power input | 110V/240V 15A-20A AC |
---|
Power load distribution | Single-phase |
---|
Frequency | 50/60 Hz |
---|
Max power output | 3.8kW @16A |
---|
Adjustable power output | Yes |
---|
|
Performance |
---|
Max charging speed (Range added per hour of charging in miles) | 15 MPH |
---|
|
Hardware |
---|
No. of charging cables (No. of EVs can charge at a time) | 1 |
---|
Holster/Dock | Simple (Separate from charging unit) |
---|
Charging cable management system | Separate from unit |
---|
Cable length | 16.4-ft (5m) |
---|
Charging connector | J1772 Type 1 |
---|
Power adapters in pack | Nema 6-20 & Nema 5-15 |
---|
Latch/Lock button on charging handle | Yes |
---|
Auto sensor button on handle to open charge port | No |
---|
|
Smart Charging Functions |
---|
LED status lights | Yes |
---|
App integration | No |
---|
Wi-Fi/Internet connectivity | No |
---|
Schedule charging | No |
---|
Charging Stats reporting | No |
---|
Power load sharing (Between multiple chargers on same circuit) | No |
---|
Access control | No |
---|
RFID feature | No |
---|
Voice Assistant | No |
---|
Automatically resume charging after power outage | Yes |
---|
Auto troubleshooting | Yes |
---|
Integrated utility companies plans detail in App | Not Applicable |
---|
Auto schedule Off-peak charging hours communication with utility providers | No |
---|
Integrated Distributed Energy Resource Management System (DERMS) | No |
---|
Software/Firmware updates | No |
---|
OCPP compliant software | Not Applicable |
---|
|
Body |
---|
|
Ambient requirements |
---|
Storage temperature range | Not specified |
---|
Operating temperature range | -22°F to +122°F (-30°C to +50°C) |
---|
Ventilation | Not specified |
---|
|
Certifications |
---|
Weather protection (Enclosure Rating) | IP65 |
---|
Energy Star certified | No |
---|
Safety Certifications | FCC, UL |
---|
|
Installation |
---|
Mounting | Wall, Portable |
---|
Installation requirements | Ready to use |
---|
Installation cost | No cost |
---|
|
Miscellaneous |
---|
Warranty | 24 months* (2 year*) |
---|
Eligible for Tax Credit/Rebates | Yes |
---|
|
Buying Price (By Variant) |
---|
Buying Price (Single Variant) | $159.99* |
---|
|
Thomas Taylor –
Was finding a portable charger for me I mostly don’t travel much but I go to camping often. So though Level 1 charger will do the job. But then I found this. Level 1 + 2 charger. I thought this is amazing. There’s a Nema 5-15 adapter for level 1 charging to be tethered upon the fixed cable Nema 6-20 for level 2 charging. That was amazing and I bought this 6 months ago.
