Basic Info |
|---|
| Charger Level | Level 2 |
|---|
| EVs compatibility | All EVs |
|---|
| is Smart Charger? | Yes |
|---|
|
|
Deployment |
|---|
| Convenience | Fixed solution at location of installation (Home-office etc) |
|---|
| Usage | Indoor, Outdoor |
|---|
|
|
Power |
|---|
| Power supply connection | Plug-in, Hardwired |
|---|
| Power input | 208V/240V 40A-80A AC |
|---|
| Power load distribution | Single-phase & Three-phase |
|---|
| Frequency | 50/60 Hz |
|---|
| Max power output | 7.7kW @32A – 15.4kW @64A single-phase |
|---|
| Adjustable power output | No |
|---|
|
|
Performance |
|---|
| Max charging speed (Range added per hour of charging in miles) | 31 MPH to 61 MPH |
|---|
|
|
Hardware |
|---|
| No. of charging cables (No. of EVs can charge at a time) | 1 |
|---|
| Holster/Dock | Simple (Separate from charging unit) |
|---|
| Charging cable management system | Integrated in unit |
|---|
| Cable length | 25-ft (7.6m) |
|---|
| Charging connector | J1772 Type 1 (Ruggedized), NACS (Ruggedized) |
|---|
| Power adapters in pack | Plug-in: Nema 6-50 or 14-50 / Hardwire: Not needed |
|---|
| Latch/Lock button on charging handle | Yes |
|---|
| Auto sensor button on handle to open charge port | No |
|---|
|
|
Smart Charging Functions |
|---|
| LED status lights | Yes |
|---|
| App integration | Yes |
|---|
| Wi-Fi/Internet connectivity | Yes (2.4GHz) |
|---|
| Schedule charging | Yes |
|---|
| Charging Stats reporting | Yes |
|---|
| Power load sharing (Between multiple chargers on same circuit) | No |
|---|
| Access control | No |
|---|
| RFID feature | No |
|---|
| Voice Assistant | No |
|---|
| Automatically resume charging after power outage | Yes |
|---|
| Auto troubleshooting | No |
|---|
| Integrated utility companies plans detail in App | Yes |
|---|
| Auto schedule Off-peak charging hours communication with utility providers | Yes |
|---|
| Integrated Distributed Energy Resource Management System (DERMS) | No |
|---|
| Software/Firmware updates | Yes |
|---|
| OCPP compliant software | Yes |
|---|
|
|
Body |
|---|
| Dimension | 500 mm (H) * 226 mm (W) * 135 mm (D) |
|---|
| Weight | 14.5 lbs. (6.6 kg) – 19 lbs. (8.6 kg) |
|---|
|
|
Ambient requirements |
|---|
| Storage temperature range | -40°F to +176°F (-40°C to +80°C) |
|---|
| Operating temperature range | -22°F to +122°F (-30°C to +50°C) |
|---|
| Ventilation | Not Required |
|---|
|
|
Certifications |
|---|
| Weather protection (Enclosure Rating) | Nema 4 |
|---|
| Energy Star certified | Yes |
|---|
| Safety Certifications | ETL, FCC, NEC, UL |
|---|
|
|
Installation |
|---|
| Mounting | Wall, Pedestal |
|---|
| Installation requirements | Plug-in: Ready to use if 240V wall outlet is ready, Else for Plug-in/Hardwired: Requires certified electrician |
|---|
| Installation cost | Plug-in: Almost No Cost if 240V Powerline and wall outlet is ready, Else for Plug-in/Hardwired: Appx. $500 to $1500+ |
|---|
|
|
Miscellaneous |
|---|
| Warranty | 60 months* (5 years*) |
|---|
| Eligible for Tax Credit/Rebates | Yes |
|---|
| What's in package | 1x Charging Unit, 1x Mounting set, Holster, Hubbell NEMA outlet, User Manual |
|---|
|
|
Buying Price (By Variant) |
|---|
| 32A | Hardwired | J1772 | $622* |
|---|
| 32A | Hardwired | NACS | $622* |
|---|
| 40A | Hardwired | J1772 | $688* |
|---|
| 40A | Hardwired | NACS | $688* |
|---|
| 48A | Hardwired | J1772 | $1099* |
|---|
| 48A | Hardwired | NACS | $1099* |
|---|
| 64A | Hardwired | J1772 | $1176* |
|---|
| 64A | Hardwired | NACS | $1176* |
|---|
| 32A | Plug-in | Nema 14-50 | J1772 | $644* |
|---|
| 40A | Plug-in | Nema 14-50 | J1772 | $710* |
|---|
| 32A | Plug-in | Nema 6-50 | J1772 | $644* |
|---|
| 40A | Plug-in | Nema 6-50 | J1772 | $710* |
|---|
|
Amelia –
Mine worked well for me. Got 40A plug-in charger installed in my garage. It fully charges my 75kW battery to in around 10 hours. Up to 80% it only takes less than 7 hours. Overall recommended. It’s costly but also sturdy.
Madison –
A very good robust EV charger. Good cable and connector material. Though around $200 higher than average cost. But worth it. Simple installation with hardwired unit.
Connie Freeman –
I liked robustness of the charger and excellent cable and connector material. Plus smart features are making it a complete home charging unit.
Henry Peters –
I bought Enphase IQ 80 64amp for my Benz EQS and it’s worth it. EVs with 90-100kWh above battery really needs powerful above 48amp charger.
I am using this since last 2 months and really appreciate the charging speed it provides. Also the look and robustness of the charger bod, cable and connector is really impressive.
It is installed on a pedestal in parking space and installation was very easy. It took just less than an hour for the electrician to install, and it was ready to charge.
I also have Tesla universal wall connector and love to drive EVs and experiment with different things, especially those powerful drives.
