Basic Info |
|---|
| Charger Level | Level 2 |
|---|
| EVs compatibility | All EVs |
|---|
| is Smart Charger? | Yes |
|---|
|
|
Deployment |
|---|
| Convenience | Fixed solution at location of installation (Home-office etc) |
|---|
| Usage | Indoor, Outdoor |
|---|
|
|
Power |
|---|
| Power supply connection | Plug-in, Hardwired |
|---|
| Power input | 208V/240V 16A-50A |
|---|
| Power load distribution | Single-phase |
|---|
| Frequency | 60Hz |
|---|
| Max power output | 12kW @50A |
|---|
| Adjustable power output | Yes |
|---|
|
|
Performance |
|---|
| Max charging speed (Range added per hour of charging in miles) | 30MPH Plug-in / 37MPH Hardwired |
|---|
|
|
Hardware |
|---|
| No. of charging cables (No. of EVs can charge at a time) | 1 |
|---|
| Holster/Dock | Simple and Flexible (Integrated in charging unit) |
|---|
| Charging cable management system | Integrated in unit |
|---|
| Cable length | 23-ft (7m) |
|---|
| Charging connector | J1772 Type 1, NACS |
|---|
| Power adapters in pack | Plug-in: Nema 6-50 or 14-50 / Hardwire: Not needed |
|---|
| Latch/Lock button on charging handle | Yes |
|---|
| Auto sensor button on handle to open charge port | No |
|---|
|
|
Smart Charging Functions |
|---|
| LED status lights | Yes |
|---|
| App integration | Yes |
|---|
| Wi-Fi/Internet connectivity | Yes (2.4/5GHz) |
|---|
| Schedule charging | Yes |
|---|
| Charging Stats reporting | Yes |
|---|
| Power load sharing (Between multiple chargers on same circuit) | No |
|---|
| Access control | No |
|---|
| RFID feature | No |
|---|
| Voice Assistant | Yes – Alexa, Siri |
|---|
| Automatically resume charging after power outage | Yes |
|---|
| Auto troubleshooting | No |
|---|
| Integrated utility companies plans detail in App | Yes |
|---|
| Auto schedule Off-peak charging hours communication with utility providers | Yes |
|---|
| Integrated Distributed Energy Resource Management System (DERMS) | No |
|---|
| Software/Firmware updates | Yes |
|---|
| OCPP compliant software | No |
|---|
|
|
Body |
|---|
| Dimension | 284.3 mm (H) * 179.4 mm (W) * 179.6 mm (D) |
|---|
| Weight | 13.8 lbs. (6.26 kg) |
|---|
|
|
Ambient requirements |
|---|
| Storage temperature range | -40°F to +140°F (-40°C to +60°C) |
|---|
| Operating temperature range | -22°F to +122°F (-30°C to +50°C) |
|---|
| Ventilation | Not Required |
|---|
|
|
Certifications |
|---|
| Weather protection (Enclosure Rating) | Nema 3R |
|---|
| Energy Star certified | Yes |
|---|
| Safety Certifications | CEC, CSA, FCC, NEC, UL |
|---|
|
|
Installation |
|---|
| Mounting | Wall, Pedestal |
|---|
| Installation requirements | Plug-in: Ready to use if 240V wall outlet is ready, Else for Plug-in/Hardwired: Requires certified electrician |
|---|
| Installation cost | Plug-in: Almost No Cost if 240V Powerline and wall outlet is ready, Else for Plug-in/Hardwired: Appx. $500 to $1500+ |
|---|
|
|
Miscellaneous |
|---|
| Warranty | 36 months* (3 years*) |
|---|
| Eligible for Tax Credit/Rebates | Yes |
|---|
| What's in package | 1x Charging Unit, 1x Charging Cable, 1x Faceplate, 1x Mounting set, 1x Mounting Template, Installation guide |
|---|
|
|
Buying Price (By Variant) |
|---|
| 50A | Hardwired | J1772 | $549* |
|---|
| 50A | Hardwired | NACS | $549* |
|---|
| 40A | Plug-in | Nema 14-50 | J1772 | $599* |
|---|
| 40A | Plug-in | Nema 14-50 | NACS | $599* |
|---|
| 40A | Plug-in | Nema 6-50 | J1772 | $599* |
|---|
| 40A | Plug-in | Nema 6-50 | NACS | $599* |
|---|
|
Woodrow Ervin –
Bought this Homeflex recently for my Kia EV. It’s working very fine. I also have Tesla M3 and using with J1772 adapter. very easy to use and set up. It was plug-in unit and I had 240V wall outlet ready in my garage. So just have been easy.
Allen Young –
Overall recommended. It’s a known company and one of the oldest making Home EV charging stations. Quality cable, connector and charging unit. Easy to use and packed smart features. I got this on a rebate. But still under $600 this is totally valuable and recommended EVSE in the market. Works perfect with different brands of EVs.
Lori Stevens –
Using hardwired version of Home Flex. Was easy to install. very easy to use. Good body and cable material and overall adding value in my EV journey. No complaints yet.
Just charging 2-3 hours early morning adds enough charge for me to travel along the day. Very happy with this.
