Tesla Universal Wall Connector

Name: Tesla Universal Wall Connector - Buy Now - Full Specifications - Reviews - Opinions - Make Informed Choice - EV Chargers Guide
Price: 580.00 USD
Availability: InStock
Rating: 5.00 (1 reviews)

★★★★★

(1 customer review)

$580.00

Key Features:

Universal Level 2 EVSE – Compatible with Tesla and non-Tesla EVs – 48 amp smart Home EV charging station – Magic Dock J1772 + NACS – 24-foot cable with integrated cable management

Max charging power: 11.5kW @48A single-phase
Charging speed: Up to 44 MPH
Charging connector: J1772 + NACS
LED status lights: Yes

*Note: Prices and warranty details may change over time and the same will be updated here at the earliest. Check More info and Latest price.

Category: Shop Home EV Chargers

Additional information
Reviews (1)

Specification: Tesla Universal Wall Connector

Basic Info

Charger Level	Level 2
EVs compatibility	All EVs
is Smart Charger?	Yes

Deployment

Convenience	Fixed solution at location of installation (Home-office etc)
Usage	Indoor, Outdoor

Power

Power supply connection	Hardwired
Power input	240V 15A to 60A Single phase or 400V 3-phase AC
Power load distribution	Single-phase & Three-phase
Frequency	50/60 Hz
Max power output	11.5kW @48A single-phase
Adjustable power output	Yes

Performance

Max charging speed (Range added per hour of charging in miles)	44 MPH

Hardware

No. of charging cables (No. of EVs can charge at a time)	1
Holster/Dock	Magic Dock (J1772 + NACS)
Charging cable management system	Integrated in unit
Cable length	24-ft (7.3m)
Charging connector	J1772 Type 1 + NACS
Power adapters in pack	Not needed
Latch/Lock button on charging handle	Yes
Auto sensor button on handle to open charge port	Yes (Works for Tesla only)

Smart Charging Functions

LED status lights	Yes
App integration	Yes
Wi-Fi/Internet connectivity	Yes (2.4GHz)
Schedule charging	Yes
Charging Stats reporting	Yes
Power load sharing (Between multiple chargers on same circuit)	Yes
Access control	Yes
RFID feature	No
Voice Assistant	No
Automatically resume charging after power outage	Yes
Auto troubleshooting	No
Auto schedule Off-peak charging hours communication with utility providers	No
Integrated Distributed Energy Resource Management System (DERMS)	No
Software/Firmware updates	Yes
OCPP compliant software	No

Body

Dimension	345 mm (H) * 155 mm (W) * 110 mm (D)
Weight	10 lbs. (4.5 kg)

Ambient requirements

Storage temperature range	-40°F to +185°F (-40°C to +85°C)
Operating temperature range	-22°F to +122°F (-30°C to +50°C)
Ventilation	Not Required

Certifications

Weather protection (Enclosure Rating)	Nema 3R
Energy Star certified	Yes
Safety Certifications	ETL

Installation

Mounting	Wall, Pedestal
Installation requirements	Requires certified electrician
Installation cost	Appx. $750 to $1500+

Miscellaneous

Warranty	48 months* (4 year) for residential use and 12 months (1 year) for commercial use
Eligible for Tax Credit/Rebates	Yes
What's in package	1x Charging Unit, 1x Mounting set, 1x Mounting Template, Installation guide, Quick Start guide

Buying Price (By Variant)

Buying Price (Single Variant)	$580*

1 review for Tesla Universal Wall Connector

5.0 out of 5

★★★★★

Write a review

Show all Most Helpful Highest Rating Lowest Rating

★★★★★
Johns Miller – June 20, 2024
I have Tesla model X and Rivian R1S and I had an old level 2 J1772 charger. I was using a NACS adapter to charge my Tesla. But I just sold it and got this J1772 + NACS universal wall connector. It really made sense to me to get this. And It just worked miraculously for me. Especially it’s magic doc saving both J1772 and NACS connector. You won’t believe me, I broke 2 NACS connector when using my older Level 2 charger and 1 got stolen!
But since I got this universal connector there’s no chance. It’s rightly called magic dock. It handles both connector smartly. One tethered over other.
+ PROS: Magic Dock - no chance of breaking or stealing of J1772 adapter connector High power 48A charging Looks classy with my home's architecture
- CONS: Could be better if having Nema 4 or higher enclosure. But it's ok works fine outdoors. But not in extreme rain. It's better installed in garage if you live in extreme rainy weather states.
